Grat AC220V Quick Open Electric Actuator Miniature Alloy Auto Electric Valve Actuator
Grat Ordinary Temperature Flange Alloy Original Auto-Electric Valve Actuator Product Description: Original Auto-Electric Valve Actuator/Ordinary Temperature/ Alloy Description: With whole stroke 0-90° to realize fully open &open single action in 4S, EA series quick switch electric actuator is ...
Quick Open Electric Actuator Miniature
,AC220V Quick Open Electric Actuator
,Alloy Auto Electric Valve Actuator
Grat Ordinary Temperature Flange Alloy Original Auto-Electric Valve Actuator
Product Description:
Original Auto-Electric Valve Actuator/Ordinary Temperature/ Alloy
Description:
With whole stroke 0-90° to realize fully open &open single action in 4S, EA series quick switch electric actuator is satisfied with quick switch requirement of ball valve, butterfly valve, and other segmental electric quick switch valve.
This actuator is suited to high pressure, large pressure drops, and the quick switch services that solenoid valve is not available, which is matched with ball valve, V type control valve, butterfly valve, ventilation valve, damper, fan, dynamic balancing valve, plug valve, gyrating valve, and mechanical positioning rotation system in other industrial area.
Features:
* GRAT new technology patent for Potentiometer Positioning Device(PPD)
* The new technology for Direct Debugging Switch(DDS) in electric actuators
* Quick switch
* 100000 times life
* Miniature design
* Good seal performance
* Good reliability
* Good pressure resistance performance
Specification:
| Torque | 20~2000NM |
| Power supply | AC220V(Custom powers are available.) |
| Control signal | switch energy |
| Action time | 4S |
| Action angle | 0~90°(180° is the maximum gyration angle |
| Modulation accuracy | ≤0.3% |
| Dead zone | ≤0.2% |
| Connection | Bracket and shaft sleeve fix actuator |
| Protection level | IP67 |
| Ambient Temp | ≤60ºC |
| Implementation standards | JB/T-8219-1999 |
Product information
Packing & Shipping:
1.Packing: inner with bubble wrap,outer with cardboard box and wooden case.
2.Transportation:by sea, by air,by train.
If you have other requirements, please feel free to tell us.
